The MARVEL-MAGNETO AUV makes advanced underwater magnetic anomaly detection accessible and cost-effective. Equipped with a high-performance fluxgate magnetometer sensor from Sensys, it provides detailed magnetic data with exceptional stability and precision. Designed to operate reliably in coastal environments affected by waves and currents, MARVEL-MAGNETO offers versatile navigation and communication features to support complex survey missions.
• High-quality fluxgate magnetometer for accurate magnetic anomaly detection
• Integrated INX navigation system, Doppler Velocity Log (DVL), and acoustic positioning for precise underwater localisation
• Absolute navigation accuracy better than 5 metres within the range of the USBL surface module
• Operational endurance up to 8 hours with speeds up to 6 knots
• Depth rating of up to 300 metres
• SEAPLAN mission software with pre-defined lawnmower patterns for efficient and repeatable survey missions
• Autonomous surface buoy equipped with USBL and dual-antenna GNSS-RTK for enhanced positioning and communication
INX Navigation System
Doppler Velocity Log (DVL)
SEAPLAN Mission Planning Software
Embedded Rechargeable Batteries
SEACOMM Communication Module
Acoustic Positioning and Communication Module
Field Case and Accessories
Autonomous Surface Buoy with USBL and GNSS-RTK
Note: The MARVEL AUV series is subject to dual-use export licensing regulations by the SBDU authority in France.
The MARVEL-MAGNETO AUV provides a reliable, easy-to-deploy solution for magnetic anomaly surveys, combining advanced sensor technology with precise navigation and robust communication for challenging marine environments. Its user-friendly design supports single-operator deployment and efficient mission execution.
Uses:
Magnetic anomaly detection
Geological and archeological surveys
UXO (unexploded ordnance) detection
Applications examples:
Mine countermeasures applications
UXO
Data Sheet:
Data Sheet:
The MARVEL-MAGNETO AUV is equipped with a fluxgate magnetometer from Sensys for detecting magnetic anomalies. It features underwater acoustic positioning, 8 hours autonomy, 6 knots speed, and 300 m depth rating. Navigation accuracy is better than 5 m within USBL range.
